1V724 - Spheric ball valve
True union grey PVC spheric ball valve, ISO metric plain solvent weld socket, with fixed ball support and radial disassembly.
EPDM or FKM seals.
PTFE ball seats.
Astore 724 is a true union ball valve for industrial and water treatment applications, with fixed ball support and radial disassembly, which allow a simple and safe installation and a reliable service over time.
Main features:
- Construction: True union grey PVC spheric ball valve, with fixed ball support and radial disassembly
- Size range: DN 10 ÷ 100
- Nominal pressure:
- DN 10÷50: PN16 with water at 20°C
- DN 65÷100: PN10 with water at 20°C
- Temperature range: 0 °C ÷ 60 °C
- Coupling standards: Solvent welding: ISO 727, EN ISO 1452-4 (model 1V724)
- Valve material: PVC-U
- Seal material:
- EPDM, FKM (O-Ring)
- PTFE (ball seats)
- Control options: Manual control
EPDM
| Reference | H | Z | DN | D | g |
|---|---|---|---|---|---|
| 1V72401600 | 51 | 54 | 10 | 16 | 150 |
| 1V72402000 | 51 | 50 | 15 | 20 | 145 |
| 1V72402500 | 59 | 53 | 20 | 25 | 220 |
| 1V72403200 | 66 | 59 | 25 | 32 | 315 |
| 1V72404000 | 77 | 68 | 32 | 40 | 505 |
| 1V72405000 | 87 | 77 | 40 | 50 | 725 |
| 1V72406300 | 105 | 98 | 50 | 63 | 1245 |
| 1V72407500 | 138 | 142 | 65 | 75 | 3400 |
| 1V72409000 | 138 | 142 | 80 | 90 | 3500 |
| 1V72411000 | 171 | 162 | 100 | 110 | 5900 |
FKM
| Reference | H | Z | DN | D | g |
|---|---|---|---|---|---|
| 1V72401610 | 51 | 54 | 10 | 16 | 150 |
| 1V72402010 | 51 | 50 | 15 | 20 | 145 |
| 1V72402510 | 59 | 53 | 20 | 25 | 220 |
| 1V72403210 | 66 | 59 | 25 | 32 | 315 |
| 1V72404010 | 77 | 68 | 32 | 40 | 505 |
| 1V72405010 | 87 | 77 | 40 | 50 | 725 |
| 1V72406310 | 105 | 98 | 50 | 63 | 1245 |
| 1V72407510 | 138 | 142 | 65 | 75 | 3400 |
| 1V72409010 | 138 | 142 | 80 | 90 | 3500 |
| 1V72411010 | 171 | 162 | 100 | 110 | 5900 |
