LS Quick Kit DN10-50
Accessories for VKD and TKD Dual Block® series ball valves DN 10÷50
The Limit Switch Quick Kit allows the fast and secure installation of the FIP LSQT to the VKD valve. The body is in PP-GR and the handle in stainless steel AISI 316. The handle block at 0° and 90° is also available by default (hole diameter 6.5 mm). The kit can be assembled on the valve even if already installed on the system. For technical data of the LSQT box see FIP actated valves catalogue.
| Reference | d | DN |
|---|---|---|
| LSQKIT20 | 20 | 15 |
| LSQKIT25 | 25 | 20 |
| LSQKIT32 | 32 | 25 |
| LSQKIT40 | 40 | 32 |
| LSQKIT50 | 50 | 40 |
| LSQKIT63 | 63 | 50 |
