POWER-LOCK bend 22° F/F PN10

Bend PVC-U, F/F, Grey RAL 7011, FORSHEDA 601 POWER-LOCK® connection.

The fittings comply with UNI EN ISO 1452, DIN 8063, ISO 2045, ISO/DIS 6455 standards for the transport of pressurised fluids for the supply of drinking water, wastewater and food fluids: oil, wine, milk.

Go back Data sheet
Pressure pipe PN10 plain end NF EN 1452
Reference D (mm) L (mm)
PBVPN10063FF2L 63 355
PBVPN10075FF2L 75 330
PBVPN10090FF2L 90 300
PBVPN10110FF2L 110 320
PBVPN10125FF2L 125 330
PBVPN10140FF2L 140 335
PBVPN10160FF2L 160 340
PBVPN10180SS2L 180* 635
PBVPN10200FF2L 200 635
PBVPN10225FF2L 225 545
PBVPN10250FF2L 250 665
PBVPN10280FF2L 280 530
PBVPN10315FF2L 315 570
PBVPN10400FF2L 400 660

*Rubber ring
