BIRXF
Adaptor for socket welding - unions
Adaptor union in PP-H/STAINLESS steel for socket welding (d), BSP (R) threaded A316L STAINLESS steel male end with O-Ring in FKM.
Series of fittings designed for conveying fluids under pressure with a hot thread and weld connection system (socket welding).
| Reference | Name | Product description | dimensionalTable | Main category | Subcategory | Sub sub category | system | Category | family | Material | d x R | R1 | PN | E | H | K | L[5:1] | Z | g |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BIRXF020012F | BIRXF | Series of fittings designed for conveying fluids under pressure with a hot thread and weld connection system (socket welding). | - | PVDF system | ISO-BSP Fittings | ISO-BSP Fittings - unions | PVDF system | Pressure Fittings | ISO-BSP Fittings | PVDF | 20 x 1/2" | 1" | 16 | 47 | 65 | 25 | 13,5 | 37,5 | 139 |
| BIRXF025034F | BIRXF | Series of fittings designed for conveying fluids under pressure with a hot thread and weld connection system (socket welding). | - | PVDF system | ISO-BSP Fittings | ISO-BSP Fittings - unions | PVDF system | Pressure Fittings | ISO-BSP Fittings | PVDF | 25 x 3/4" | 1"1/4 | 16 | 58 | 71,5 | 32 | 15 | 40,5 | 242 |
| BIRXF032100F | BIRXF | Series of fittings designed for conveying fluids under pressure with a hot thread and weld connection system (socket welding). | - | PVDF system | ISO-BSP Fittings | ISO-BSP Fittings - unions | PVDF system | Pressure Fittings | ISO-BSP Fittings | PVDF | 32 x 1" | 1"1/2 | 16 | 65 | 78 | 38 | 17,5 | 42,5 | 333 |
| BIRXF040114F | BIRXF | Series of fittings designed for conveying fluids under pressure with a hot thread and weld connection system (socket welding). | - | PVDF system | ISO-BSP Fittings | ISO-BSP Fittings - unions | PVDF system | Pressure Fittings | ISO-BSP Fittings | PVDF | 40 x 1"1/4 | 2" | 16 | 78 | 87 | 48 | 19,5 | 47,5 | 558 |
| BIRXF050112F | BIRXF | Series of fittings designed for conveying fluids under pressure with a hot thread and weld connection system (socket welding). | - | PVDF system | ISO-BSP Fittings | ISO-BSP Fittings - unions | PVDF system | Pressure Fittings | ISO-BSP Fittings | PVDF | 50 x 1"1/2 | 2"1/4 | 16 | 85 | 95 | 55 | 19,5 | 52,5 | 700 |
| BIRXF063200F | BIRXF | Series of fittings designed for conveying fluids under pressure with a hot thread and weld connection system (socket welding). | - | PVDF system | ISO-BSP Fittings | ISO-BSP Fittings - unions | PVDF system | Pressure Fittings | ISO-BSP Fittings | PVDF | 63 x 2" | 2"3/4 | 16 | 103 | 113,5 | 69 | 24 | 62,5 | 1200 |
